Main Application：

Mainly suitable for welding of all kinds of PVC inflatable toys, such as inflatable sofa, inflatable mattress for children, children's inflatable tub, swimming ring, inflatable ball, inflatable cartoon, inflatable entertainment, inflatable advertising media, inflatable swimming pool, etc.Also can be used as PVC blister packing, canvas membrane structure welding and so on purpose, achieve multi-usage and welding effect is firm.

Character：

■Frequency stability, high frequency machine adopts the vacuum tube, stable output power, oscillation frequency 13.56 MHz, USES the international industrial band in line with international standards;

■Use powerful type head, pressure can be adjusted, and design using the toggle push lever principle, can make the uniform pressure, on smoothly, to match the needs of different degree of weld depth, especially suitable for difficult matchup products.

■Avoid interference of waves device: the high frequency stabilizer and high frequency shielding device, the high frequency interference to a minimum.

■Output power: the low loss of coaxial resonator, can with the fastest time make welding products, greatly improve the production.

■Over-current protection system: automatic over-current protection system, can increase the service life of the vacuum tube, protect the mould.

■Heating device: stepless heating temperature control device, can be in accordance with the production needs of different products, adjustable temperature, making work more efficient.

■Safety protection device: when the current load exceeds limit, overload current relay will automatically cut off the high pressure, to protect oscillation tubes and rectifier;In addition, the machine is equipped with high sensitive spark suppressor, at the same time, can avoid the frequency drift caused by improper operation.

Welding mould(die)：

High frequency machine must work with high frequency welding die. More than getting perfect welding and cutting effect,we do some special treatment on the welding die by ourselves to make it more durable. Our client can use it for about 10 million times without any replacement of the down mould.

Service：

1. Recommend equipment of top choice based on your requirements for product;

2. test for client freely, and send the sample back for checking

3. Providing assistance in manufacturing and modifying tools;

4. OEM/ODM accepted.

5. Warranty for one year
